KYF/XCF Flotation Cell
Self-absorbing slurry type aerated flotation equipment with low tailings deposition, low circumferential velocity and low energy consumption.
- Coarse preparation of copper, lead and zinc mixed ore
- Purification of graphite/fluorite/phosphate rock
- Upgrade of old production lines
What is Sandreck KYF/XCF Flotation Cell
As a professional manufacturer and supplier in China, Sandreck KYF/XCF Flotation Cell is upgraded on the basis of KYF flotation machine technology, which can realize accurate sorting of both metallic ores such as copper, iron and non-metallic ores such as graphite and fluorite. It works together with the vertical slurry circulation system through the external blower low pressure air supply, which greatly improves the flotation efficiency.
Sandreck KYF/XCF Flotation Cell Advantages
Vertical circulation + low-pressure airflow dual effects, mineral recovery rate increased by more than 10%.
We are a large-scale manufacturer and supplier, and the factory has many types of flotation machines for sale at low prices.
Equipped with touch screen, PLC system, you can monitor parameters such as inflation volume and foam thickness in real time.
Stable operation under extreme conditions of PH value 4-12 and slurry concentration 25-45%.
Modular design + wear-resistant lining, key component replacement time is shortened by 40%.
Closed structure reduces reagent volatilization, combined with tail water circulation system, help you easily pass environmental assessment.
Why Choose Sandreck KYF/XCF Flotation Cell?
Sandreck KYF/XCF Flotation Cell supports flexible horizontal or ladder type layout, adapting to the needs of different sizes of beneficiation plants, taking into account the processing capacity (single machine 20-350m³/h) and energy saving performance (energy consumption reduced by 18-30%), which is the core equipment of modernized beneficiation workshop.
More About Our Company
- Technical Parameter
Model | Effective Volume (m³) | Tank Size(m) | Impeller | Power (kw) | Blower Air Pressure (kpa) | Air Consumption/ Tank(m³/min) | Capacity (m³/min) | |
| Diameter (mm) | Speed (m/s) | |||||||
| KYF-2 | 2 | 1.30×1.30×1.25 | 0.41 | 5.3 | 5.5 | >16 | 00-3 | 0.5-2 |
| XCF-2 | 0.46 | 7.5 | 7.5 | 0.5-1 | ||||
| KYF-3 | 3 | 1.60×1.60×1.40 | 0.48 | 5.5 | 7.5 | ≥18 | 00-5 | 0.7-3 |
| XCF-3 | 0.55 | 7 | 11 | 0.7-1.5 | ||||
| KYF-4 | 4 | 1.80×1.80×1.50 | 0.55 | 5.76 | 11 | ≥19.8 | 00-6 | 1-4 |
| XCF-4 | 0.62 | 7.3 | 15 | 1-2 | ||||
| KYF-8 | 8 | 2.20×2.20×1.95 | 0.63 | 6 | 15 | ≥21.5 | 00-10 | 1-2 |
| XCF-8 | 0.72 | 7.5 | 22 | 2-4 | ||||
| KYF-16 | 16 | 2.80×2.80×2.40 | 0.74 | 6.2 | 30 | ≥25.5 | 0-15 | 4-16 |
| XCF-16 | 0.88 | 7.8 | 37 | 4-8 | ||||
| KYF-20 | 20 | 3.02×3.02×2.70 | 37 | ≥25 | 0-16 | 5-20 | ||
| XCF-20 | 45 | 6-10 | ||||||
| KYF-24 | 24 | 3.10×3.10×2.90 | 0.8 | 6.84 | 37 | ≥30 | 0-17 | 6-24 |
| XCF-24 | 0.92 | 7.95 | 55 | 6-12 | ||||
| KYF-38 | 38 | 3.8×3.80×3.40 | 0.9 | 6.9 | 55 | ≥34.3 | 0-25 | 8-38 |
| XCF-38 | 1.05 | 8.15 | 75 | 8-19 | ||||
| KYF-50 | 50 | 4.20×4.20×3.50 | 75 | ≥33 | 0-25 | 15-50 | ||
| XCF-50 | 90 | 15-40 | ||||||
We are a manufacturer of Flotation Cell, integrating manufacturing, production and supply in one. We have a professional after-sales team, there are original parts to provide, maintenance costs are very low.
Sandreck have a dedicated production team. The delivery time of Sandreck Flotation Cell is generally made within 20 days after the contract is signed.
You can send us a message on WhatsApp（+86 +13666293477） or leave your contact details on our website, later our online customer service will contact you to give you the info of Sandreck Flotation Cell.
